Technical Specifications

Sizes

XXS (46cm), XS (49cm), S (52cm), M (54cm), L (56cm), XL (58cm), XXL (61cm)

Color(s)

Satin Black / Orange

Frame

C10 high-modulus carbon w/ VRTech, integrated head tube w/ 1 1/2" lower, internal cable routing, PF30 BB shell, double water bottle mounts, oversized ETC chainstays, flat-mount disc system, 12mm convertible thru-axle system w/ replaceable hanger & hidden fender eyelet

Fork

FC-440 carbon monocoque w/ VRTech, tapered carbon steerer, 12mm thru-axle dropout, hidden fender eyelet

Crankset

Oval Concepts 300, forged 6066 arms, Praxis rings, 50/34T

Bottom Bracket

Praxis PF30 conversion bottom bracket

Pedals

N/A

Front Derailleur

Shimano 105, braze-on mount

Rear Derailleur

Shimano 105 GS

Shifters

Shimano 105 Dual Control Hydraulic, 11-speed

Cassette

Shimano HG-700, 11-34T

Chain

KMC X11 w/ MissingLink

Wheelset

Oval Concepts 324 Disc, centerlock hubs, 100x12mm & 142x12mm thru axles, 700c 24/28H rims

Tires

Vittoria Zaffiro Pro, 700 x 30, 60tpi, folding

Brakeset

Shimano 105 Hydraulic, 160/160 rotors

Brake Levers

Shimano 105 Hydraulic

Headset

FSA, 1 1/8" upper - 1 1/2" lower, integrated

Handlebar

Oval Concepts 310 Ergo, 6061 alloy, 31.8mm clamp, 133mm drop, 4° sweep

Stem

Oval Concepts 313, 3D-forged 6061 stem body, +/-7°

Tape

Anti-Slip Silicone

Saddle

Oval Concepts 344, steel rail

Seatpost

Oval Concepts 905, carbon & alloy, 27.2mm diameter

Weight

TBD
