Sizes
S (15"), M (17"), L (19"), XL (21"), XXL (23")
Color(s)
Lime Green, Satin Black
Frame
Fuji A2-SL custom-butted alloy front triangle, Fuji A1-SL alloy rear triangle
Fork
SR Suntour SF19-XCT30-HLO-DS-29 w/ hydraulic lockout, 100MM
Crankset
Shimano Tourney, 42/34/24T
Bottom Bracket
VP-BC73, sealed cartridge bearing
Pedals
Resin platform
Front Derailleur
Shimano Tourney
Rear Derailleur
Shimano Acera
Shifters
Shimano Altus, Rapid Fire, 3 x 8-speed
Cassette
Shimano HG31, 11-34T, 8-speed
Chain
KMC HV700
Wheelset
WTB SX19 rims 32H, Formula DC-20 front, DC-22 rear hubs, black spokes
Tires
WTB Ranger Comp, 29" x 2.25", 30tpi
Brakeset
Tektro HD-M275, 180/160MM rotors
Brake Levers
Tektro HD-M275
Headset
1 1/8" cartridge bearings
Handlebar
Oval Concepts flat bar, alloy, 710MM
Stem
Fuji Mountain, forged aluminum, +/-6°
Grips
Fuji Performance Grip
Saddle
Oval Concepts Sport
Seat post
Oval Concepts, alloy, 30.9MM
Weight
14.57 kg. / 32.13 lbs.
Geometry
|
Size |
S |
M |
L |
XL |
XXL |
|||||
|---|---|---|---|---|---|---|---|---|---|---|
|
Bike Size |
15" |
17" |
19" |
21" |
23" |
|||||
|
Seat Tube, Center To Top |
380 |
430 |
483 |
530 |
580 |
|||||
|
Top Tube, Effective |
580 |
600 |
625 |
640 |
660 |
|||||
|
Head Tube Length |
100 |
110 |
115 |
120 |
130 |
|||||
|
Seat Tube Angle |
73° |
73° |
73° |
73° |
73° |
|||||
|
Head Tube Angle |
70° |
70° |
70° |
70° |
70° |
|||||
|
Chainstay Length |
435 |
435 |
435 |
435 |
435 |
|||||
|
Wheelbase |
1074.5 |
1095 |
1120.3 |
1135.6 |
1155.8 |
|||||
|
Bottom Bracket Drop |
60 |
60 |
60 |
60 |
60 |
|||||
|
Fork Offset |
46 |
46 |
46 |
46 |
46 |
|||||
|
Stack |
624.9 |
634.3 |
639 |
643.7 |
653.1 |
|||||
|
Reach |
389.1 |
406.2 |
429.7 |
443.3 |
460.4 |
|||||
|
Standover |
652.7 |
697.8 |
727 |
758.2 |
787.3 |
|||||
|
Stem |
70 |
80 |
90 |
100 |
100 |
|||||
|
Handlebar Width |
710 |
710 |
710 |
710 |
710 |
|||||
|
Crank |
170 |
175 |
175 |
175 |
175 |
|||||
|
Wheel Size |
29" |
29" |
29" |
29" |
29" |
|||||
|
Seat Post Diameter |
30.9 |
30.9 |
30.9 |
30.9 |
30.9 |
|||||
